Logitech 960-001680 MeetUp 2 4K All-in-One Video Conference Camera
In Stock at Warehouse
- 960-001680
- 960-001680
- VIDEO CONFERENCE
Logitech MeetUp 2 4K All-in-One Video Conference Camera - Resolution: 1080p - Camera: 4K, 4X HD digital zoom - Diagonal FOV: 120 - Microphones Frequency Response: 90Hz 16kHz - Digital PTZ camera - Interfaces: HDMI Out: 1, HDMI In: 1, USB: 1 x Type C USB 3.1 - Network: 10/100/1G Ethernet - WiFi: 802.11a/b/g/n/ac - Bluetooth: Bluetooth Low Energy - 960-001680
| · One Mount, Three Ways |
| · Works With Your Preferred Platform |
| · Easy To Manage |
| · AI-Enhanced Meetings |
| · Simple And Flexible Deployments in Small Rooms |
Upgrade your small meeting rooms with MeetUp 2, a USB conference camera for small spaces powered by AI features that simplify the meeting experience for both employees and IT.
SPECS & DETAILS
TECHNICAL SPECIFICATIONS
Overview
Built-in Components
6 DMIC microphone array
Digital PTZ camera
1 full range ported speaker
Cable management & retention system
Multi-mount
Logitech CollabOS platform
Logitech RightSight 2
Logitech RightSound 2
General Specifications
Enclosure: All-in-one enclosure
Device Management: Logitech Sync
Displays Supported: BYOD mode: 1; Dedicated computer mode: computer/application dependent
Display Resolution: 1080p
Network Protocol Support: IPv4, IPv6
Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file
Camera
Digital pan: ±48° at 4x zoom
Digital Tilt: ±32° at 4x zoom
Zoom: 4X HD digital zoom
Diagonal Field of View: 120°
Horizontal Field of View: 113°
Vertical Field of View: 80°
Resolution: 4K
Speakers
Driver: 55 mm with bass reflex enclosure and patented suspension design
Sensitivity: 83 dB SPL @1W +/-2dB @ 1 metre
Rated Power: 8W THD at 1W, 1kHz : <2%
Speaker Sampling Rate: 48KHz
Impedance: 4 Ohms
Microphones
Frequency Response: 90Hz – 16kHz
Sensitivity: -36dBFS +/-1 dB @ 1Pa
Microphone data rate output: 48 kHz
Pickup Range: Up to 7m
Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams
Audio processing: AEC (Acoustic Echo Cancellation) VAD (Voice Activity Detector)
Noise suppression: AI based de-noising algorithm
Interfaces
HDMI Out: 1
HDMI In: 1
USB: 1 x Type C USB 3.1
Network: 10/100/1G Ethernet
WiFi: 802.11a/b/g/n/ac
Bluetooth: Bluetooth® Low Energy
Power and Cables
Power supply: Auto-sensing
Operating Voltage/Power: 100-240V, 19V, 2.1A
Power Supply Dimensions: 114 x 47 mm x 32.3 mm
DC Cable: 3 m
USB C to USB C 3.0 Cable: 3 m
Environmental
Operating Temperature: 0 to 40°C
Storage Temperature: -25-70°C
Humidity: 10 to 90%
Security
File Based Encryption: AES-128
Data Encryption: Symmetric Keys, PKI
Device Identity: Protected by device attestation
Device Access: Authenticated using API
Key Protection: Arm TrustZone, RPMP
Physical Security: Kensington security slot
DIMENSIONS
Height: 73.3 mm
Width: 469.2 mm
Depth: 73 mm
Weight: 1.8 kg
COMPATIBILITY
Windows 10 and higher
macOS: two most recent versions
Network Connection: wired or wireless
PACKAGE CONTENTS
All-in-one MeetUp 2 with multi-function mount
Power supply with region-specific plugs
USB-C to USB-C 2.0 cable that is 3 m
2 wall anchors and 2 screws
Quick start guide printed on the box
WARRANTY INFORMATION
2-Year Limited Hardware Warranty
PART NUMBER
960-001680
