Ubiquiti 24VDC @ 0.5A Gigabit PoE POE-24-12W-G Adapter

Model
POE-24-12W-G

Dimensions
87 x 84 x 29.2 mm (3.43 x 3.31 x 1.15 in)

Weight
99.4 g (3.51 g)

Output Voltage
24VDC @ 0.5A

LAN Activity Indicator
No

Gigabit LAN Port
Yes

Remote Reset Capability
Yes

Reset Button
Yes

Input Voltage
90-260VAC @ 47-63 Hz

Input Current
0.3A @ 120VAC,
0.2A @ 240VAC

Inrush Current
<30A Peak @120VAC,
<60A Peak @ 230VAC

Efficiency
75+%

Output Ripple
1% Max.

Switching Frequency
50 kHz

Line Regulation
± 1%

Load Regulation
± 3%

4-Pair Powering
Pins 4, 5 (+) and Pins 7, 8 (-)

Operating Temperature
0 to 40°C (32 to 104°F)

Storage Temperature
-30 to 70°C (-22 to 158°F)

Operating Humidity
35 to 95% Non-Condensing

AC Connector
IEC-320 C6

Data IN / POE
RJ45 Shielded Socket

Surge Protection
Difference and Common Mode

Clamping Protection
11V Data, 60V Power

Max. Surge Discharge
1500A (8/20μS) Power

Peak Pulse Current
36A (10/1000μS) Data

Shunt Capacitance
<5 pf data

Response Time
<1 nS

Compliance
IEC 60950-1:2005+A1
UL60950-1
EN55022:2010, EN55024:2010
FCC Class B

AC Cable with Earth Ground
USA, EU, AR, BR, UL, CCC, Mexico
