Ubiquiti Next-Generation Gateway Pro 1U Security UXG-Pro Gateway
In Stock at Warehouse
- UXG-Pro
- UXG-Pro
- NETWORKING
Ubiquiti Networks UXG-PRO Next-Generation Gateway Pro 1U Security Gateway - Processor: Quad-Core ARM Cortex-A57 1.7GHz - System Memory: 2GB DDR4 - Display: 1.3" Touchscreen - Ports: 10/100/1000Mbps RJ45 LAN, 10/100/1000Mbps RJ45 WAN, 10G SFP+ LAN, 10G SFP+ WAN - Management Interface: Ethernet - Power Method: Universal AC Input, 200-240VAC, 50/60Hz - Form Factor: 1U Rackmountable - 12 Months Limited Warranty
| · Powered by a 1.7 GHz quad-core processor |
| · Features 2 WAN ports (GbE RJ45/10G SFP+) with failover support and 2 LAN ports (GbE RJ45/10G SFP+) |
| · Enterprise-class DPI, IPS/IDS, and layered firewall configuration |
| · 1U-sized, rack-mountable form factor |
| · SmartPower outlet (125VAC/2A) for an external modem |
Dual-WAN security gateway designed to protect medium to large-sized networks with enterprise-class firewall configuration and threat management features.
The Dual-WAN Gateway Pro offers an enterprise-grade firewall and a deep set of threat management features.
1.7 GHz quad-core processor
(2) WAN ports (GbE RJ45 and 10G SFP+) with failover support
(2) LAN ports (GbE RJ45 and 10G SFP+)
Enterprise-class DPI, IPS/IDS, and layered firewall configuration
SmartPower outlet (125VAC/2A) for an external modem
1U-sized, rack-mountable device
Powerful Gateway
The UniFi Next-generation Gateway Pro is a powerful security gateway that delivers a versatile networking interface and enterprise-class threat management functionality to medium to large-sized networks. The UXG Pro provides the high-speed connectivity needed to support the most bandwidth-intensive applications. It also excels as a complete network security solution, offering a full suite of threat mitigation features, including deep packet inspection (DPI), intrusion detection and prevention systems (IDS/IPS), and layered firewall configuration.
UniFi OS designed for multi-application use
Seamless integration within a single management interface. The UXG Pro can be paired with a Cloud Key Plus (sold separately) to create a highly powerful and secure deployment that can be fully managed with the UniFi Network application (web/mobile).
442.4 x 43.7 x 285.6 mm
3.42 kg
Front panel: aluminum CNC
Top cover/base: SGCC steel
Quad-core ARM® Cortex®-A57 at 1.7 GHz
2 GB DDR4
Ethernet
LAN:
(1) 1 GbE RJ45 port
(1) 10G SFP+ port
WAN:
(1) 1 GbE RJ45 port
(1) 10G SFP+ port
(1) 1.3" touchscreen
Bootup animation: bootup in progress
Firmware upgrade icon: firmware upgrading
Factory reset
US:
(1) Universal AC input, 125VAC, 2.7A max., 60 Hz
(1) RPS DC input, 11.5VDC, 2.87A
Worldwide:
(1) Universal AC input, 200-240VAC, 1.7A max., 50/60 Hz
(1) RPS DC input, 11.5VDC, 2.87A
AC/DC, internal, 50W
30W
Air: ± 15 kV, contact: ± 8 kV
-10 to 40° C
5 - 95% noncondensing
CE, FCC, IC
Blue
Green / Amber
White / Green
Networking
- 10/100/1000 Mbps
